Oracle Cloud : Autonomous Database (ADW or ATP) - Export Data to an Object Store (expdp)

Oracle Cloud, Oracle Database Exam Prep, Oracle Database Career, Oracle Database Preparation, Oracle Database Tutorial and Materials

This article demonstrates how to export data from an Autonomous Data Warehouse (ADW) or Autonomous Transaction Processing (ATP) service on the Oracle Cloud using the expdp utility.

◉ Assumptions

For the export to work you will have to make a connection from an Oracle client to the ADW or ATP database. You can see the necessary setup to do this here.

The Oracle 18c impdp utility introduced the CREDENTIAL parameter to specify the object store credential to be used for an import. From Oracle 21c (21.3) we can also use the CREDENTIAL parameter with the expdp utility.

We need an object store bucket to export the data to. This could be an Oracle Cloud Object Storage bucket, or an AWS S3 bucket.

◉ Create Something to Export

We connect to an autonomous database and create a new test user.

conn admin/MyPassword123@obatp_high

create user testuser1 identified by "MyPassword123";

alter user testuser1 quota unlimited on data;

grant create session to testuser1;

grant dwrole to testuser1;

We create a test table which we will export.

create table testuser1.t1 as

select level as id,

       'Description for ' || level as description

from   dual

connect by level <= 1000;

commit;

◉ Object Store Credentials

Create a credential for your object store. For an Oracle object storage bucket we use our Oracle Cloud email and the Auth Token we generated.

conn admin/MyPassword123@obatp_high

begin

  dbms_cloud.drop_credential(credential_name => 'obj_store_cred');

end;

/

begin

  dbms_cloud.create_credential (

    credential_name => 'obj_store_cred',

    username        => 'me@example.com',

    password        => '{my-Auth-Token}'

  ) ;

end;

/

For AWS buckets we use our AWS access key and secret access key.

begin

  dbms_cloud.create_credential (

    credential_name => 'obj_store_cred',

    username        => 'my AWS access key',

    password        => 'my AWS secret access key'

  );

end;

/

◉ Export to Object Store

We can use a local Oracle 21.3 installation to export data from the autonomous database to an object store.

We use the CREDENTIALS parameter to point to the database credential we created earlier. We use an object store URI for the DUMPFILE location. For AWS S3, use the URI of your S3 bucket. For Oracle Cloud the URI can take either of these forms.

https://swiftobjectstorage.{region}.oraclecloud.com/v1/{namespace}/{bucket-name}/{file-name}.dmp

https://objectstorage.{region}.oraclecloud.com/n/{namespace}/b/{bucket-name}/o/{file-name}.dmp

The following example uses the "swiftobjectstorage" URI.

expdp admin/MyPassword123@obatp_high \

      tables=testuser1.t1 \

      directory=data_pump_dir \

      credential=obj_store_cred \

      dumpfile=https://swiftobjectstorage.uk-london-1.oraclecloud.com/v1/my-namespace/ob-bucket/t1.dmp \

      exclude=statistics

Export: Release 21.0.0.0.0 - Production on Tue Sep 7 18:36:39 2021

Version 21.3.0.0.0

Copyright (c) 1982, 2021, Oracle and/or its affiliates.  All rights reserved.

Connected to: Oracle Database 21c Enterprise Edition Release 21.0.0.0.0 - Production

Starting "ADMIN"."SYS_EXPORT_TABLE_01":  admin/********@obatp_high tables=testuser1.t1 directory=data_pump_dir

  credential=obj_store_cred dumpfile=https://swiftobjectstorage.uk-london-1.oraclecloud.com/v1/my-namespace/ob-bucket/t1.dmp exclude=statistics

Processing object type TABLE_EXPORT/TABLE/TABLE_DATA

Processing object type TABLE_EXPORT/TABLE/TABLE

. . exported "TESTUSER1"."T1"                            32.60 KB    1000 rows

ORA-39173: Encrypted data has been stored unencrypted in dump file set.

Master table "ADMIN"."SYS_EXPORT_TABLE_01" successfully loaded/unloaded

******************************************************************************

Dump file set for ADMIN.SYS_EXPORT_TABLE_01 is:

  https://swiftobjectstorage.uk-london-1.oraclecloud.com/v1/my-namespace/ob-bucket/t1.dmp

Job "ADMIN"."SYS_EXPORT_TABLE_01" successfully completed at Tue Sep 7 18:37:14 2021 elapsed 0 00:00:26

$

The following example uses the "objectstorage" URI.

expdp admin/MyPassword123@obatp_high \

      tables=testuser1.t1 \

      directory=data_pump_dir \

      credential=obj_store_cred \

      dumpfile=https://objectstorage.uk-london-1.oraclecloud.com/n/my-namespace/b/ob-bucket/o/t1.dmp \

      exclude=statistics

Export: Release 21.0.0.0.0 - Production on Tue Sep 7 19:05:47 2021

Version 21.3.0.0.0

Copyright (c) 1982, 2021, Oracle and/or its affiliates.  All rights reserved.

Connected to: Oracle Database 21c Enterprise Edition Release 21.0.0.0.0 - Production

Starting "ADMIN"."SYS_EXPORT_TABLE_01":  admin/********@obatp_high tables=testuser1.t1 directory=data_pump_dir

  credential=obj_store_cred dumpfile=https://objectstorage.uk-london-1.oraclecloud.com/n/my-namespace/b/ob-bucket/o/t1.dmp exclude=statistics

Processing object type TABLE_EXPORT/TABLE/TABLE_DATA

Processing object type TABLE_EXPORT/TABLE/TABLE

. . exported "TESTUSER1"."T1"                            32.60 KB    1000 rows

ORA-39173: Encrypted data has been stored unencrypted in dump file set.

Master table "ADMIN"."SYS_EXPORT_TABLE_01" successfully loaded/unloaded

******************************************************************************

Dump file set for ADMIN.SYS_EXPORT_TABLE_01 is:

  https://swiftobjectstorage.uk-london-1.oraclecloud.com/v1/my-namespace/ob-bucket/t1.dmp

Job "ADMIN"."SYS_EXPORT_TABLE_01" successfully completed at Tue Sep 7 19:06:06 2021 elapsed 0 00:00:15

$

◉ Get the Log File

If we want to read the contents of the expdp log file we can push it across to the object store using the PUT_OBJECT procedure in the DBMS_CLOUD package.

conn admin/MyPassword123@obatp_high

begin

  dbms_cloud.put_object(

    credential_name => 'obj_store_cred',

    object_uri      => 'https://swiftobjectstorage.uk-london-1.oraclecloud.com/v1/my-namespace/ob-bucket/export.log',

    directory_name  => 'data_pump_dir',

    file_name       => 'export.log');

end;

/

It can then be downloaded from the object store.

Source: oracle.com
